2025 Ranger XD 1500 NorthStar Edition Ultimate
Exterior Color
Titanium Metallic
Polaris Pursuit Camo
Ghost White
LEGEND:
S = Series O = Optional
Brakes
S
Parking Brake - Park In-Transmission
S
Front/Rear Brakes - Foot activated and power assisted, 4 wheel hydraulic disc with dual-bore front and rear calipers
ENGINE/DRIVETRAIN
S
Fuel System/Battery - Electronic Fuel Injection
S
Cooling - Liquid
S
Horsepower - 110 HP
S
Fuel Capacity - 11.35 gal (43 L)
S
Cylinders Displacement - 1498cc
S
Engine Braking System (EBS) - Drive Mode Specific Engine Braking System. Hill Assist enables the vehicle to hold its position, allowing easier maneuvering and improved control when stopping and starting on hills
S
Transmission/Final Drive -STEELDRIVE Automatic Transmission: D/R/P
S
Engine Type - 4-Stroke DOHC Triple Cylinder
S
Drive System Type - On-Demand True AWD/2WD/Turf/Ultra Turf, Drive Modes: Comfort, Standard, Sport, Tow/Haul, Equipped with creep in drive and reverse to help with low speed drivability for smoother power delivery
Dimensions
S
Person Capacity - 3
S
Payload Capacity -1,705 lb. (773 kg)
S
Hitch Towing Rating - 3,500 lbs. (1588 kg)
S
Bed Box Dimensions - 43.4 x 56 x 13.4 in (110.2 x 142.2 x 34 cm)
S
Wheelbase - 95 in. (241.3 cm)
S
Ground Clearance - 15 in (38 cm)
S
Estimated Dry Weight - 2,800 lbs. (1,270 kg)
S
GVW - 4,600 lbs. (2,087 kg)
S
Overall Vehicle Size - 137 x 65 x 78 in (348 x 165 x 198 cm)
Tires/Wheels
S
Tire Ply Rating - 8 Ply Rated
S
Electronic Power Steering -High Output EPS
S
Rear Tires - 30 x 11-15; KENDA CROSS TRAIL
S
Front Tires - 30 x 10-15; KENDA CROSS TRAIL
S
Wheels - 15" Aluminum
Additional Specifications
S
Hitch Type - Standard 2 in (5 cm) Receiver
S
Adjustable Driver Seat
S
Hitch Towing Rating - 3,500 lbs. (1588 kg)
S
Cargo System - Lock & Ride MAX
S
Lighting - LED Headlights w/ LED Taillights, LED Rear Work Light, LED Dome Light, Door Puddle Lighting, Front LED Aux Light, Interior Accent Lighting, Lighting Modes: Low, High, Accent, Blackout. Blackout mode switches off the headlights and dims interior lighting
S
Instrumentation -7” Display Powered by RIDE COMMAND: Plow Mode, Group Ride, GPS Navigation, Bluetooth, AM/FM Radio; Factory Rear Camera; Driver Forward Information Center w/ 4 in Color Display + Analog Speedometer & Tachometers: User Selectable Blue/Red Backlighting & Brightness, Speedometer, Tachometer, Odometer, Tripmeter, Clock, Hour Meter, Gear Indicator, Fuel Gauge, Coolant Temperature, Oil Pressure, Transmission Indicator, EPS Indicator, Voltmeter, Service Indicator and Codes, Seat Belt Reminder, Speed Limiting
S
Other Standard Features - Premium Pro-Shield Cab, Doors with Full Power Windows, Tipout Glass Windshield with Wiper, Rear Glass Panel, Dome Light, Door Puddle Lighting, Interior Accent Lighting, Rearview Mirror, Heat, AC, Defrost. Premium Heated Front Contoured Seats with Additional Bolstering, Premium Headrests and Center Armrest. Premium, Telescoping Steering Wheel and Painted Interior Accents. Polaris Pulse Electrical System (6 position), 140 Amp Charging System. Front Bumper with D-Rings, Top Bar and Integrated LED Auxillary Lights. Overhead Switch Panel, DC Outlet, USB Charge Port, Trickle Charger, 12V Cargo Box Power Port, NorthStar Badge. Polaris Pro HD 6,000 lb. Synthetic Rope Winch with Autostop and Rapid Rope Recovery plus Wireless Remote
S
Tilt Steering - Tilt & Telescoping Steering
Suspension
S
Rear Suspension - Dual Arched A-Arm IRS 12" (30.5 cm) Travel
S
Front Suspension - Dual A-Arm 12" (30.5 cm) Travel
S
Turning Radius- 15.1 ft. (4.6 m)
